Clamped Sight Glass

This compact lens sight glass offers fast and simple installation with minimal maintenance needs, making it suitable for food, dairy, and pharmaceutical applications. It features an extremely compact construction with a large viewing area and no product entrapment, while ensuring full CIP/SIP compatibility and autoclavability. Designed for maximum hygiene, it provides clear visibility and optimal performance under varying conditions.

Advantages :

• Fast and simple installation and maintenance
• Suitable for food, dairy and pharmaceutical applications
• Extremely compact construction with large viewing area
• No product entrapment
• CIP/SIP – Autoclavable

Operating conditions :

• Design Pressure: -1 bar to 10.3 barg (-14.5 psi to 150 psig)
• Design Temperature: -80°C to 150°C (-112°F to 302°F)

Material :

• Lens Cover: AISI 316L stainless steel
• Clamp: AISI 304 stainless steel (optional)
• Glass Lens: Borosilicate tempered glass to DIN 7080
• Clamp gasket: Silicone, EPDM, Viton (optional)
• Lens cushion gasket: PTFE

Surface finish :

• Product contact surface finish: 15 - 20 Ra

Marking :

• Each Lens cover is marked with Heat No. for full lot traceability

Dimensions table (in mm) :

CODE	TC	ID	A	B	C	Borosilicate glass		P max	T max
						OD	Thk
MA.C15.C00.35.0	50.4	34.8	35.0	44.0	13.0	40.5	8	10.3 bar	150°C
MA.C20.C00.35.0	64.0	47.5	47.5	56.0	13.5	52.5	8	10.3 bar	150°C
MA.C25.C00.35.0	77.5	60.2	60.0	70.0	14.0	66.0	8	10.3 bar	150°C
MA.C30.C00.35.0	91.0	72.9	72.5	84.0	14.0	78.5	8	10.3 bar	150°C
MA.C40.C00.35.0	119.0	97.4	84.0	110.0	16.0	104.5	10	10.3 bar	150°C
